151 chair & 152, 153 stool
Planos copia de: Base details - Seat cushion - Assembly details - Exploded views - Assembly details & details of swivel mechanism - Bearing washer - Nylon bushing - Detail of steel glide - Tubing insert for alum. base - Insert for radial bearing. Diseñador: Eero Saarinen. -
2451, 3452 & 3454 tables
Planos copia de: Elevations, plans & details - Leg & spacer details - Assembly details. Diseñador: RICHARD SCHULTZ. -
3710, 3711, 3712, 3714 & 3716 tables
Planos copia de: Assembly details - Wood top details - Top clip details - Marble top details - Glas top details. Diseñador: Warren Platner. -
4144, 4146, 4164 & 4166 double pedestal desks
Planos copia de: Elevations, plans, sections, details - St’l legs & angles for both wood steel and all steel bases - Sections showing lock & locking device - St’l leg with adj. glide; St’l angles with lugs; plans, elevations, details. Locking device details & sections - Plan & elevations, 76” x 36” x 29” ht. (both). Diseñador: RICHARD SCHULTZ. -
55 - 161, 163, 169 & 171 Marcel line
Plano copia de: Exploded view. “Marcel Line” podría referir a un diseñador. -
68, 70, 71, 72, 180 & 181 swivel chairs
Plano copia de: Full size detail... - Metal base details - Plan & cross section of seat cushion - Seat & shell details - Details - Plastic shell detail - Plywood seat detail - Swivel only & fixed base assembly for capped bases - Top plate details for fixed & swvel only bases - Drill jig - Assembly details - Spider spacer - New spider - Seat & shell detail - Laminated wood leg base - ... mech. steel ... -
68, 71, 72, 180 & 181 swivel chairs
Planos copia de: Caped base deatils - Ctr tube for wood swivel base armature - Caster socket for wood swivel base using helms control. Diseñador: Eero Saarinen. Otras láminas del proyecto en FKI - PLc082-0075. -
-
7441 & 7442 chaise lounge
Planos copia de: Elevations & details - Molded wheel & tire - Details of stretcher used for factory assembly of slings to frame. Diseñador: RICHARD SCHULTZ. Otras láminas del proyecto en FKI - PLr113-0067. -
7441 & 7442 chaise lounge
Planos copia de: Full size details - Flat bar seat support - Exploded view of metal parts - Details of st’l flat bar - Hinge pin for flat bar - Nylon strip for flat bar hinge - Exploded vierw of metals parts. Diseñador: RICHARD SCHULTZ. Otras láminas del proyecto en FKI - PLc080-0073. -
-
Bastiano Line: 53 145 lounge chair, 53 146 settee & 53 147, 148 sofas
Planos copia de: Exploded view - Leg panel details - Back panel details - Seat frame details (53 145 lounge chair) - Seat frame details (for 53 146 settee & 53 147 148 sofas) - Back clip - Brass ferrule platner desk line. -
Bertoia chairs: 420, 421, 422, 423, 424, 425, 426
Planos copia de: Lopp connector - Details of base - Relations of basket to base - Wires - Basket weld tester - Base detail - Rubber seat template - Rubber back template - Approved contour - Base details & scale elevations of complete chairs - Seat connector details - Upholstery clip detail - Steel rod base - Full size section - Template for rubber seat pads - Partial steel rod base - Assembly details ... -
Cadeira
Planos copia de: Planta e frente - Elev. lat - Assento e encosto estofado - Frente e lateral do braco - Planta elev. perfil (concha braco assento) - Assento e encosto compensado - Base giratoria s/ rodizios - Base giratoria - Versoes modelos - Cadeira. Hoja carta con apuntes. -
Cafiero cabinet
Planos copia de: Locking bracket doors - Connecting link bracket. Diseñador: Vincent Cafiero. -
Cesca Chair
Planos copia de: Back frame (50 112 & 116 Cesca side chairs) - Seat frame detail (50 111 MC & 115 MC, caned, 50 112 & 116, inset uphol, Cesca chair) - Seat pan detail (50 112 & 116 Cesca chair) - Polyfoam seat (50 112 & 116 Cesca chair) - Seat reinforcement plate Cesca chair - Polyfoam back (50 111U & 115U Cesca chairs) - Polyfoam seat (50 111U & 115U Cesca chairs) - Tubing frame details (50 115 & ... -
Cesca Chair
Planos copia de: Laminated seat (50 111U & 115U Cesca chairs) - Inner back panel (50 111U & 115U Cesca chair) - Outer back panel (50 111U & 115U Cesca chairs) - Extruded upholstery edge (50 111U & 115 Cesca chairs) - Steel inserts for back panel (50 111U & 115U Cesca chairs) - Back frame (50 111MC & 115MC Cesca chairs) - Assembly details (50 111U & 115U Cesca chairs) - End cap for tubing bases - ... -
Diffrient shell chair
Planos copia de: Controls & columns exploded view - Multiple seating-arm & armless exploded view & bill of material - 1180 7 arm & armless standard chairs exploded views - 1180 7 arm & armless deluxe chairs exploded views. Diseñador: Neils Diffrient. -
D’Urso Collection: tables
Planos copia de: Insert, caster (high tables) - Extrusion glass top corner (table low roller) - Bracket support laminated tops (high tables) - Insert leg top high table - Bolck location stone tops - Support ballast plate - Bracket support for stone tops (high tables) - Rail top frames (high tables) - Weldment leg & caster insert high table - Glide molded table leg - Bracket corner for high rolling ... -
Eldon Tables
Planos copia de: Assembly details - Exploded view and bill of material - Leg details - Rail details - Top support rails - Top details - Marble top details. Diseñador: Jim Eldon. Una de las láminas con copia.
