Zapf Office System

Abstract

Planos copia de: Assembly pedestal bill of material - Case assemblies for pedestals - Panel sides & back for pedestals - Channel support for pedestals - Channel front vertical 5.703 H. for single box drawer ZS IBOF - Zee back vertical for details - Locking bars for pedestal s - Channel front vertical (11.672 H.) for ZS 2BOF, ZS 2BIF, ZS IS & ZS IC pedestals - Channel front vertical (17.641 H.) for ZS IBIF & ZS 3BOF pedestals - Channel front vertical (23.609 H.) for ZS 4BOF, ZS OB2F & ZS IF pedestals - Box drawer body assy w/o drawer front - Panel sides & bottom for box drawer body - Panel side outer for box drawer body - Panel front outer for box drawer body - Panel back outer for box drawer body - Panel outer outer for box drawer front - Panel inner outer for box drawer front - Front box drawer - Divider box drawer - Clip divider box drawer - Panel outer for file drawer front & pedestal door - Panel inner file drawer front - Front file drawer - File drawerbody assy. w/o drawer front - Panel sides & bottom for file drawer body. Diseñador: Otto Zapf.
